Yokogawa 701505 4-Ch,120K Word,200Ms/S,Digital Oscilloscope
Please use the request form to start a calibration services quote. You may also request equipment sales or repair services.
Description
The Yokogawa 701505 Digital Oscilloscope is a powerful and versatile instrument designed for high-precision waveform measurement and analysis across various electronic applications. With four channels, a memory depth of 120K words per channel, and a sampling rate of up to 200 megasamples per second (Ms/s), this oscilloscope is well-equipped to handle a wide range of signal types, from fast transients to complex waveforms. Ideal for engineers and technicians involved in research, development, and troubleshooting, the Yokogawa 701505 offers advanced triggering options, a high-resolution display, and comprehensive connectivity features. Its user-friendly interface and robust performance make it an essential tool for accurate and efficient signal analysis.
Specifications:
- Channels: 4
- Memory Depth: 120K words per channel
- Sampling Rate: Up to 200 Ms/s
- Bandwidth: Typically up to 100 MHz (model dependent)
- Vertical Resolution: 8 bits
- Input Impedance: 1 MΩ ±1%
- Input Coupling: AC, DC, GND
- Trigger Types: Edge, Pulse, Video, and more
- Display: High-resolution color LCD
- Connectivity: USB, LAN, and GPIB for remote control and data transfer
- Power Supply: 100-240V AC, 50-60 Hz
- Dimensions: Compact and portable design, rack-mountable
- Weight: Approx. 6 kg
- Operating Temperature: 0°C to 40°C
- Storage Temperature: -20°C to 60°C
- Additional Features: Math functions, FFT analysis, and waveform memory for enhanced analysis
