Yokogawa 701410 1Gs/S,500Mhz,4Ch,2Mw,Digital Oscilloscope
Please use the request form to start a calibration services quote. You may also request equipment sales or repair services.
Description
The Yokogawa 701410 Digital Oscilloscope is a high-performance instrument engineered for detailed waveform observation and analysis in advanced electronic applications. It features four channels, a sampling rate of up to 1 gigasample per second (Gs/s), and a bandwidth of 500 MHz, ensuring accurate capture of high-frequency signals. With a memory depth of 2 million words (Mwords) per channel, the 701410 can store extensive waveform data, making it suitable for capturing long signal sequences. This oscilloscope is ideal for engineers and researchers working on high-speed digital circuits, RF signals, and complex electronic systems. Its robust design, advanced triggering options, and high-resolution display facilitate precise and efficient signal analysis.
Specifications:
- Channels: 4
- Memory Depth: 2M words per channel
- Sampling Rate: Up to 1 Gs/s
- Bandwidth: 500 MHz
- Vertical Resolution: 8 bits
- Input Impedance: 1 MΩ ±1%
- Input Coupling: AC, DC, GND
- Trigger Types: Edge, Pulse, Video, Window, and more
- Display: High-resolution color LCD
- Connectivity: USB, LAN, and GPIB for remote control and data transfer
- Power Supply: 100-240V AC, 50-60 Hz
- Dimensions: Compact and portable design, rack-mountable
- Weight: Approx. 7 kg
- Operating Temperature: 0°C to 40°C
- Storage Temperature: -20°C to 60°C
- Additional Features: Math functions, FFT analysis, advanced waveform memory, and extensive analysis tools
