Teledyne Lecroy Sda 3000 3 Ghz, 20 Gs/S 2 Ch (10 Gs/S, 4 Ch), 8 Mpts/2Ch; 4 Mpt/Ch St
Please use the request form to start a calibration services quote. You may also request equipment sales or repair services.
Description
The Teledyne Lecroy SDA 3000 is a high-performance oscilloscope that offers a bandwidth of 3 GHz and a sample rate of 20 Gs/S on its two channels. With the option to expand to four channels, the sample rate can be reduced to 10 Gs/S. The oscilloscope also boasts a deep memory of 8 Mpts on two channels and 4 Mpts per channel when all four channels are used simultaneously. This allows for capturing and analyzing complex waveforms with precision and accuracy. The SDA 3000 is an ideal tool for engineers and researchers working on high-speed digital designs, telecommunications, and other applications that require advanced signal analysis capabilities.
Specifications
– Model: Teledyne Lecroy SDA 3000
– Bandwidth: 3 GHz
– Sample rate: 20 Gs/S (2 channels), 10 Gs/S (4 channels)
– Memory depth: 8 Mpts (2 channels), 4 Mpts (4 channels)
– Number of channels: 2 channels (expandable to 4 channels)
– Vertical resolution: 10 bits
– Input impedance: 50 Ω
– Input coupling: AC, DC, GND
– Trigger types: Edge, Pulse Width, Runt, Timeout, Transition, Logic, Pattern, State, Setup/Hold, Window, Qualified, Delay, Comm, Bus
– Trigger modes: Auto, Normal, Single
– Waveform measurements: Amplitude, Average, Base, Burst Width, Cycle Area, Duty Cycle, Fall Time, Frequency, High, Low, Maximum, Mean, Median, Minimum, Overshoot, Period, Peak to Peak, Phase, Rise Time, RMS, Skew, Standard Deviation, Time Interval, Top, Width
– Serial decode and trigger support for I2C, SPI, UART/RS-232, CAN, LIN, FlexRay, USB, Ethernet, MIL-STD-1553, ARINC 429, Audio, I2S, LJ, PS/2, Manchester, NRZ, RZ, I3C, SPMI, PMBus, SVID, HDMI, DisplayPort, MIPI D-PHY, MIPI CSI-2, MIPI DSI-2, DigRF, DigRF v4, DDR, LPDDR, LPDDR2, LPDDR3, LPDDR4, LPDDR5, HBM, HMC, JTAG, SWD, SDCard, eMMC, SDIO, SD, UFS
– Advanced analysis tools: Eye Diagram, Histogram, Jitter Analysis, Mask Test, Protocol Analysis, Waveform Histogram, Waveform Parameter Search, WaveScan Search
– Connectivity: USB, Ethernet, GPIB (optional)
– Dimensions: 15.1″ x 19.2″ x 10.0″ (H x W x D)
– Weight: 29 lbs.
