Teledyne Lecroy 9354A 500 Mhz, Digital Oscilloscope
Please use the request form to start a calibration services quote. You may also request equipment sales or repair services.
Description
The Teledyne Lecroy 9354A is a high-performance digital oscilloscope with a bandwidth of 500 MHz. This oscilloscope is designed to offer precise and accurate measurements for a wide range of applications. With its advanced technology, it provides users with the ability to capture and analyze complex waveforms with ease. The 9354A offers a large display screen, allowing for easy viewing of waveforms and measurements. Its user-friendly interface and intuitive controls make it suitable for both experienced professionals and beginners. Additionally, this oscilloscope is equipped with various advanced features, such as advanced triggering options, extensive measurement capabilities, and versatile connectivity options. Overall, the Teledyne Lecroy 9354A is a reliable and efficient tool for electronic engineers and technicians in need of a high-performance oscilloscope.
Specifications
– Bandwidth: 500 MHz
– Channels: 4
– Sample Rate: 10 GS/s
– Memory Depth: 10 Mpts/Ch
– Vertical Resolution: 12 bits
– Rise Time: <700 ps
– Display: 12.1″ TFT color touchscreen
– Input Impedance: 1 MΩ || 12 pF
– Input Coupling: AC, DC, GND
– Trigger Types: Edge, Glitch, Runt, Width, Interval, Pattern, TV, Setup/Hold, Window, Dropout, Transition, UART, I2C, SPI, CAN, LIN, FlexRay, MIL-STD-1553, Audio, USB, Ethernet
– Connectivity: USB, LAN, GPIB, VGA, HDMI
– Compliance Testing: USB 2.0, HDMI 1.4, Ethernet 10/100/1000Base-T, SATA 2.6, DisplayPort 1.2, PCI Express Gen 1/2/3, I2C, SPI, CAN, LIN, FlexRay, MIL-STD-1553, Audio
– Advanced Math Functions: FFT, Integration, Differentiation, Square Root, Exponential, Logarithmic, Absolute Value, Peak Detect, Average, Envelope, etc.
– Serial Decode and Triggering: I2C, SPI, CAN, LIN, FlexRay, MIL-STD-1553, UART, USB, Ethernet
– Power Analysis: Voltage, Current, Power, Harmonics, THD, Power Factor
– Dimensions: 375 mm x 186 mm x 150 mm
– Weight: 4.6 kg
