Teledyne Lecroy 9350V 4 Ch Digital Oscilloscope 1Ghz Bandwidth 20Gs/S
Please use the request form to start a calibration services quote. You may also request equipment sales or repair services.
Description
The Teledyne Lecroy 9350V is a high-performance digital oscilloscope with four channels and a bandwidth of 1GHz. It offers a sampling rate of 20Gs/S, allowing for precise and accurate measurements of fast signals. With its advanced features and capabilities, this oscilloscope is ideal for a wide range of applications, including research and development, manufacturing, and troubleshooting electronic circuits. It provides a clear and detailed display of waveforms, enabling users to analyze and understand complex signals with ease. The Teledyne Lecroy 9350V is a reliable and efficient tool for professionals in the electronics industry, offering exceptional performance and versatility.
Specifications
– Model: Teledyne Lecroy 9350V
– Number of Channels: 4
– Bandwidth: 1 GHz
– Sample Rate: 20 Gs/s
– Vertical Resolution: 8 bits
– Input Coupling: AC, DC, GND
– Input Impedance: 1 MΩ || 14 pF
– Maximum Input Voltage: 400 Vrms CAT I, derate at higher frequencies
– Trigger Types: Edge, Pulse Width, Runt, Window, Timeout, Logic, Setup/Hold, Rise/Fall Time, Video, I2C/SPI/UART, CAN/LIN/FlexRay, USB 2.0
– Trigger Modes: Auto, Normal, Single
– Waveform Capture Rate: Up to 250,000 waveforms per second
– Memory Depth: Up to 100 Mpts per channel
– Timebase Range: 500 ps/div to 1000 s/div
– Display: 10.4″ color touchscreen LCD
– Connectivity: USB, LAN, GPIB (optional)
– Power Supply: 100-240 VAC, 50/60 Hz
– Dimensions: 17.1″ x 7.4″ x 16.6″ (W x H x D)
– Weight: 23.3 lbs
