Tektronix TBS1072B Oscilloscope
Please use the request form to start a calibration services quote. You may also request equipment sales or repair services.
Description
The Tektronix TBS1072B Oscilloscope is a high-quality, reliable, and user-friendly instrument used for measuring and analyzing electrical signals. With a bandwidth of 70 MHz and a sample rate of 1 GS/s, this oscilloscope offers exceptional performance and accuracy. It features a bright 7-inch color display with a 800×480 resolution, providing a clear and detailed view of waveforms. The TBS1072B also offers advanced triggering options, such as pulse width and video triggering, allowing users to capture and analyze complex signals with ease. Additionally, it includes a USB port for easy data transfer and storage, as well as a built-in help menu for quick and convenient access to information. Overall, the Tektronix TBS1072B Oscilloscope is a versatile and efficient tool for engineers, technicians, and students in various fields, making it an excellent choice for anyone in need of accurate signal analysis.
Specifications
– Bandwidth: 70 MHz
– Maximum real-time sample rate: 1 GS/s
– Equivalent-time sample rate: 50 GS/s
– Record length: 2.5k points
– Vertical resolution: 8-bit
– Input channels: 2
– Vertical sensitivity: 2 mV – 5 V/div
– Rise time: <5 ns
– Trigger types: Edge, Pulse Width, Video, Runt, Timeout, Window, Slope, Pattern
– Waveform math: Add, Subtract, Multiply, Divide, FFT
– Display: 7-inch TFT color display with 800 x 480 resolution
– Connectivity: USB host/device, LAN, GPIB (optional)
– Dimensions: 14.2″ x 6.2″ x 5.4″
– Weight: 6.6 lbs
