Tektronix Dpo4054B Digital Phosphor Oscilloscope, 500Mhz, 2.5Gs/S, 20M Record L
Please use the request form to start a calibration services quote. You may also request equipment sales or repair services.
Description
The Tektronix DPO4054B Digital Phosphor Oscilloscope is a powerful and versatile instrument designed for professionals in the field of electronics. With a bandwidth of 500Mhz and a sampling rate of 2.5Gs/S, it offers exceptional signal fidelity and accuracy for precise measurements. The 20M record length allows for capturing and analyzing longer periods of data, enabling users to thoroughly investigate and troubleshoot complex waveforms. Equipped with advanced digital phosphor technology, this oscilloscope provides a unique and intuitive display that allows users to easily identify signal anomalies and anomalies. Its user-friendly interface, coupled with a wide range of features and capabilities, makes the DPO4054B an indispensable tool for engineers and technicians working on a wide range of applications, from telecommunications to automotive electronics.
Specifications
– Model: DPO4054B
– Type: Digital Phosphor Oscilloscope
– Bandwidth: 500MHz
– Sampling Rate: 2.5Gs/s
– Record Length: 20M
– Channels: 4
– Vertical Resolution: 8 bits
– Input Impedance: 1 MΩ || 13 pF
– Max Input Voltage: 300 Vrms CAT II
– Rise Time: ≤700 ps
– Display: 9-inch color TFT LCD
– Display Resolution: 800 x 480 pixels
– Trigger Types: Edge, Pulse Width, Video, Runt, Pattern, State, Setup & Hold, Window, Timeout, Serial
– Math Functions: Add, Subtract, Multiply, Divide, FFT, Square Root
– Connectivity: USB, LAN, GPIB (optional)
– Dimensions: 355 mm x 173 mm x 147 mm
– Weight: 2.2 kg
