Rigol Vs5202D 100 Mhz, Mixed Signal Oscilloscope – 2+16 Digital Ch
Please use the request form to start a calibration services quote. You may also request equipment sales or repair services.
Description
The Rigol VS5202D is a powerful mixed signal oscilloscope (MSO) with a bandwidth of 100 MHz, designed to provide detailed and accurate analysis of both analog and digital signals. It features two analog channels and sixteen digital channels, enabling users to simultaneously monitor and troubleshoot intricate electronic systems. This dual capability makes the VS5202D ideal for applications in embedded system development, communications, and automotive electronics. The oscilloscope offers advanced triggering options and high-resolution sampling, which ensure precise waveform capture and facilitate the identification of subtle signal anomalies. Its user-friendly interface and comprehensive measurement tools streamline the testing process, allowing for efficient and effective analysis. Additionally, the VS5202D is compatible with Rigol’s software suite, enhancing its functionality with robust data analysis and reporting capabilities. This combination of versatility, precision, and ease of use makes the Rigol VS5202D an essential tool for engineers, technicians, and researchers seeking reliable performance in their electronic measurement tasks.
Specifications
– Rigol VS5202D:
– 100 MHz bandwidth
– Mixed signal oscilloscope
– 2 analog channels
– 16 digital channels
– Digital channels have 500 MHz timing and 250 MHz state analysis
– 10.1″ high-resolution display
– Maximum waveform capture rate: 110,000 wfms/s
– Memory depth: 140 Mpts
– Waveform update rate: 180,000 wfms/s
– Built-in 2-channel waveform generator
– Supports multiple trigger types and advanced triggering capabilities
– USB, LAN, HDMI, and optional GPIB connectivity options
