Keysight N5406A Logic Analyzer
Please use the request form to start a calibration services quote. You may also request equipment sales or repair services.
Description
The Keysight N5406A Logic Analyzer is a powerful and versatile tool designed for digital system debugging and verification. It offers advanced capabilities to capture, analyze, and troubleshoot digital signals with high accuracy and speed. With a maximum input rate of 2.5 GHz, it can handle complex digital circuits and provide detailed insights into signal behavior. The Logic Analyzer has a large storage capacity, allowing users to capture and analyze long sequences of data. Its intuitive user interface and comprehensive set of analysis tools make it easy to navigate and identify signal anomalies. The Keysight N5406A Logic Analyzer is a reliable and efficient solution for engineers and technicians working on digital systems, offering precise measurements and valuable insights to facilitate troubleshooting and design optimization.
Specifications
– Model: N5406A
– Type: Logic Analyzer
– Channels: 68
– Sample Rate: Up to 4 Gb/s
– Memory Depth: Up to 64 Mb
– Trigger Modes: Edge, Pattern, State, Sequence, and Duration
– Input Voltage Range: -6 V to +6 V
– Input Impedance: 100 kΩ || 1 pF
– Input Thresholds: TTL, CMOS, ECL, PECL, LVDS, LVPECL, CML, SSTL, HSTL, EIA
– Input Termination: 50 Ω, 100 Ω, 200 Ω, Hi-Z
– Time Base Accuracy: ± 20 ppm
– Time Base Range: 500 ms/div to 100 ps/div
– Display: 12.1″ color touch screen
– Connectivity: USB 3.0, Ethernet, GPIB
– Power Supply: 100-240 VAC, 50/60 Hz
– Dimensions: 442 mm x 331 mm x 198 mm
– Weight: 9.3 kg
