Keysight M8030A Bit Error Ratio Test
Please use the request form to start a calibration services quote. You may also request equipment sales or repair services.
Description
The Keysight M8030A Bit Error Ratio Test (BERT) is a highly advanced and efficient tool used in the field of communication and electronic testing. Designed by Keysight Technologies, a leading provider of electronic measurement solutions, the M8030A BERT is capable of accurately measuring the quality and performance of digital communication systems. It assesses the bit error ratio, which is the ratio of erroneous bits to the total number of transmitted bits, providing vital information about the reliability and integrity of the system under test. With its advanced features, such as an adjustable data rate, low intrinsic jitter, and flexible clocking options, the M8030A BERT enables engineers to thoroughly evaluate the performance of high-speed data links, ensuring optimal functionality and minimizing potential errors or failures.
Specifications
– Bit rate: 1.5 Gb/s to 32 Gb/s
– Input signal: PRBS (Pseudo Random Binary Sequence)
– Input level: 400 mVp-p to 1.6 Vp-p
– Input impedance: 50 Ω
– Input connector: SMA
– Output connector: SMA
– Output level: 400 mVp-p to 1.6 Vp-p
– Output impedance: 50 Ω
– Clock source: Internal or external
– Clock input: SMA
– Pattern length: 7, 9, 11, 15, 20, 23, 31, or 511 bits
– Error detection: Real-time error detection and counting
– Error measurement: BER (Bit Error Ratio)
– Error analysis: Eye diagram, Bathtub curve, Histogram, Jitter, Rise and fall time measurements
– Jitter analysis: RJ, PJ, DJ, TIE, ISI, and input jitter decomposition
– Compliance testing: PCIe, USB, Ethernet, SATA, HDMI, DisplayPort, CPRI, OBSAI, and others
– User interface: Graphical user interface (GUI) with touchscreen display
– Remote control: SCPI commands over LAN or USB
– Power requirement: 100-240 VAC, 50/60 Hz
– Dimensions: 2U rack-mountable (88 mm x 426 mm x 465 mm)
– Weight: Approximately 13 kg
