Keysight 8349B 2 to 20 GHz Microwave Amplifier (Agilent)
Please use the request form to start a calibration services quote. You may also request equipment sales or repair services.
Description
The Keysight 8349B, previously branded under Agilent, is a high-performance microwave amplifier designed to operate over a wide frequency range of 2 to 20 GHz. This device is well-regarded for its ability to provide consistent amplification, offering a typical gain of 22 dB, which makes it an essential component for applications requiring signal amplification across this broad spectrum. The 8349B is equipped with a robust design to ensure reliability and stability in various testing and operational environments, including laboratory and field settings. Its compact size and ease of integration with other equipment make it a versatile choice for engineers and technicians working in communications, radar, and electronic warfare. The amplifier’s performance and precision are supported by Keysight’s reputation for quality and innovation in electronic measurement and testing solutions.
Specifications
- Frequency Range: 2 to 20 GHz
- Typical Gain: 22 dB
- Gain Flatness: ±1.5 dB
- Noise Figure: 8.5 dB typical
- Output Power (P1dB): +20 dBm typical
- VSWR (Input/Output): 2.5:1
- Harmonic Distortion: -20 dBc typical
- Third-Order Intercept Point (IP3): +30 dBm typical
- Power Requirements: 100, 120, 220, or 240 VAC, 48 to 66 Hz
- Dimensions: 104.1 mm (4.1 in) H x 215.9 mm (8.5 in) W x 355.6 mm (14 in) D
- Weight: 7.3 kg (16 lbs)
- Connector Type: Precision Type-N (female)
- Operating Temperature Range: 0 to +55°C
- Storage Temperature Range: -40 to +70°C
- Reliability: MTBF of 60,000 hours
also available with the following specs and models:
- Microwave Amplifier – 2-20GHz
also known or formerly known as:
- Agilent 8349B Amplifier
