Gw Instek GDS-3254 250Mhz, 4 Ch, Visual Persistence DSO
Please use the request form to start a calibration services quote. You may also request equipment sales or repair services.
Description
The GW Instek GDS-3254 250MHz, 4 Ch, Visual Persistence DSO is an advanced digital storage oscilloscope that is highly effective in accurately analyzing waveforms. It has a wide range of capabilities, including a bandwidth of 250MHz and four channels, which allows users to measure and analyze signals in various ways. The visual persistence feature enables the display of multiple waveforms on top of each other, making it easy to identify patterns and abnormalities in measurements. Additionally, this DSO has a high sampling rate and memory depth, ensuring precise and detailed waveform capture. With its user-friendly interface and comprehensive measurement functions, the GW Instek GDS-3254 is a versatile tool suitable for engineers and technicians in different fields.
Specifications
– Brand: GW Instek
– Model: GDS-3254
– Bandwidth: 250MHz
– Number of Channels: 4
– Display: Visual Persistence DSO (Digital Storage Oscilloscope)
– Sample Rate: 2GSa/s (2 Billion Samples per second)
– Memory Depth: 140Mpts (Mega points)
– Vertical Resolution: 8 bits
– Input Coupling: AC, DC, GND
– Input Impedance: 1MΩ ±1%, 15pF ±3pF
– Maximum Input Voltage: 300Vrms, CAT II
– Trigger Types: Edge, Pulse Width, Runt, Windows, Interval, Dropout, Pattern, Video
– Connectivity: USB Host, USB Device, LAN (Ethernet), GPIB (optional)
– Display: 8-inch TFT LCD color display with 800×600 resolution
– Dimensions: 340mm x 177mm x 95mm (W x H x D)
– Weight: 2.5kg (approx.)
