Amber 3500 Distortion Analyzer
Please use the request form to start a calibration services quote. You may also request equipment sales or repair services.
Description
The Amber 3500 Distortion Analyzer is a sophisticated instrument engineered to provide precise measurement and analysis of distortion in audio signals. It is designed with advanced technology and meticulous attention to detail, ensuring exceptional accuracy and reliability in distortion measurement applications. Featuring a user-friendly interface and intuitive controls, the Amber 3500 simplifies the process of distortion analysis, making it accessible to both seasoned professionals and newcomers alike. Its robust construction ensures durability and longevity, making it suitable for use in a variety of settings, from professional audio studios to research laboratories. Equipped with a comprehensive range of features, including customizable measurement parameters and real-time monitoring capabilities, the Amber 3500 offers unparalleled versatility in distortion analysis. Whether performing routine quality control checks or conducting in-depth research studies, this analyzer delivers consistent and precise results, making it an indispensable tool for audio engineers, researchers, and enthusiasts alike.
Specifications
- Product Name: Amber 3500 Distortion Analyzer
- Interface: User-friendly interface for easy operation
- Controls: Intuitive controls for efficient navigation
- Construction: Robust construction for durability
- Features: Comprehensive range of features for versatile analysis
- Real-time Monitoring: Allows for monitoring of distortion in real-time
- Customizable Parameters: Enables customization of measurement parameters
- Compatibility: Compatible with various audio signal sources
- Application: Suitable for professional audio studios, research laboratories, and more
Signal Source
Frequency Range 10 Hz to 100 kHz resolution to 0.005%
Amplitude Range 10 Vrms to < 1 mVrms open circuit
THD 50 Hz to 10 kHz <0.005% (-106dB)
Unbalanced Floating or Grounded Output (Balanced 600 ohms Balanced 900 ohms Unbalanced 50 ohms)
Analyzer Section
Frequency Range 8.5 Hz to >500 kHz
Level Range 100 Vrms to <10 uVrms (+40 dBV to -100 dBV)
Level Flatness +- 0.25 dB or better
Wideband Residual Noise (600 ohms 20 Hz to 100 kHz A weighting) <2.5 uV / -112 dBm
Narrowband Residual Noise (600 ohm 1 kHz bandpass) <0.7 uV / -123 dBm
Frequency Measurement
9.5 Hz to 105 kHz 5 digits
accuracy better than 100 ppm
THD + N Measurement
frequency range 9.5 Hz to 105 kHz
THD+N range >32% to 0.0000% (>-10 dB to -120 dB)
Fundamental rejection 120 dB or better
Standard Filters
400 Hz High Pass 60 dB per decade Butterworth Response
30 kHz Low Pass 60 dB per decade Butterworth Response
80 kHz Low Pass 60 dB per decade Butterworth Response
