Agilent E2900A Pulse/Data Generators
Please use the request form to start a calibration services quote. You may also request equipment sales or repair services.
Description
The Agilent E2900A Pulse/Data Generator is a high-performance instrument designed to generate precise and reliable pulse and data signals for a variety of testing and research applications. This versatile generator is ideal for use in digital and analog circuit testing, telecommunications, and signal integrity analysis. With its wide frequency range, precise timing control, and multiple output channels, the E2900A offers exceptional flexibility and accuracy in signal generation. The instrument supports various pulse patterns and data formats, making it suitable for simulating complex signal scenarios. Its user-friendly interface and comprehensive software tools enable easy setup and operation, while advanced features like programmable output levels and synchronization capabilities enhance its functionality. The Agilent E2900A is a valuable tool for engineers and researchers who require high-quality signal generation for their testing and development projects.
Specifications
- Frequency Range: 1 Hz to 200 MHz
- Pulse Width Range: 5 ns to 1 s
- Rise/Fall Time: < 2 ns (typical)
- Output Channels: 2 independent channels
- Output Voltage: ±10 V (into 50 ohms)
- Timing Resolution: 100 ps
- Jitter: < 50 ps (typical)
- Data Formats: NRZ, RZ, PRBS, and custom patterns
- Modulation Types: AM, FM, PM
- Output Impedance: 50 ohms
- Connector Type: BNC
- Trigger Modes: Internal, external, gated, burst
- Synchronization: Yes, with external clock input
- Programming Interfaces: GPIB, USB, LAN
- Display: Color LCD with graphical user interface
- Power Supply: 100-240 V AC, 50/60 Hz
- Dimensions: 426 mm x 177 mm x 380 mm (16.8 in x 7.0 in x 15.0 in)
- Weight: Approximately 8 kg (17.6 lbs)
Agilent E2900A is also available with the following specs and model:
- Data Generator System Mainframe
