Agilent 8683B Signal Gen/Synthesizers/Sweepers
Please use the request form to start a calibration services quote. You may also request equipment sales or repair services.
Description
The Agilent 8683B Signal Gen/Synthesizer/Sweeper is a versatile and efficient tool designed for creating signals and synthesizing frequencies. It is widely used in industries like telecommunications, aerospace, and research labs due to its superior performance and advanced features. This instrument offers a wide range of frequencies, precise frequency resolution, and low phase noise, ensuring accurate and dependable signal generation. Additionally, it has sweep capabilities, allowing users to create continuous waveforms with varying frequencies for frequency response analysis and testing. Its user-friendly interface and intuitive controls make it easy to operate, while its sturdy design ensures durability and long-lasting performance. Overall, the Agilent 8683B Signal Gen/Synthesizer/Sweeper is a highly reliable and efficient tool that meets the challenging demands of modern signal generation and synthesis applications.
Specifications
– Frequency range: 100 kHz to 1.5 GHz
– Output power: -137 to +7 dBm (typical)
– Frequency resolution: 1 Hz
– Frequency switching speed: <10 ms
– Harmonics: -30 dBc (typical)
– Non-harmonics: -50 dBc (typical)
– Frequency accuracy: ±5 ppm (typical)
– Amplitude accuracy: ±1 dB (typical)
– Amplitude flatness: ±1 dB (typical)
– Phase noise: -110 dBc/Hz at 20 kHz (typical)
– Spurious outputs: -60 dBc (typical)
– Modulation capabilities: AM, FM, Phase, Pulse, and Sweep
– GPIB and RS-232 interfaces for remote control
– Compact size and lightweight design
Agilent 8683B also available with the following specs and models:
- Microwave Signal Generator – 2.3-6.5GHz
